Modular Linked Glass Rooflight

Brett Martin Glass Link Rooflight

Glass Link is a system of versatile, elegantly designed, factory glazed rooflight modules equally at home on residential projects, or larger scale commercial property developments. All modules, including those which open, are flush delivering a clean and minimalist appearance.

Glass Link is manufactured to specific requirements and easy to fit on both new build or refurbishment projects. Factory glazed modules simply lap together to form continuous rooflights of unlimited length and daylight is maximised through large glazed areas and minimal framework.

FEATURES

Rooflights with all fixed modules are secured by design as standard

Rooflights with opening modules include optional manual or mains powered operation depending on size

Multipane modules – can be glazed with multiple panes avoiding heavier and more expensive glass specification

Powered opening modules include wall switch, remote and rain sensor control options, as well as control panels for simultaneous operation

Special glass options: solar control, tinted, obscure and self-cleaning

BENEFITS

Fast and simple installation thanks to large modules and no additional flashings – modules simply lap together and side fix

Guaranteed weather tightness with factory glazed modules requiring no on site glazing sealant

Suitable for pitches of 2o-35o providing a versatile solution for a variety of applications

Elegant aluminium framework powder coated to fashionable anthracite grey RAL 7016 outside and white RAL 9010 inside

Minimalist appearance including flush powered opening modules with hidden actuators and cables, meaning fixed and opening modules appear identical

Highly thermally efficient with thermally broken frame and units glazed with Low-E insulated double glazed glass units

Safety of those below and above the rooflight assured thanks to a laminated inner pane and the product achieving non-fragility to CWCT TN-67 (for class 2 roofs) and Class B non-fragile to ACR[M]001 when new and fully installed to Brett Martin installation guidelines

Highly secure fixed Glass Link rooflights achieve secured by design accreditation

10 year commercial product warranty

BRE Globally Verified EPD (Environmental Product Declaration) – specific configurations
